Home >  Product >  MOSFET >  Power MOSFET
Product N/P 封装 Vds (V) Vgs(V) ID(A) Vth (V) Rdson_10V(mΩ) Rdson_4.5V(mΩ) 规格书 Rdson_2.5V(mΩ)
mintypmaxTypMaxTypMaxTypMax
Reset
P-ch MOS
N-ch MOS
Dual-P
Dual-N
PDFN3.3*3.3-8L
DFN2020-6L
DFN2020-6
SOP-8
DFN2*2-6
DFN2*3-6
DFN3*3
DFN2*5-6
TSSOP8-6
SOT-23-6
TO-252
PDFN3.3*3.3
TO-220
PDFN5*6
SOT-23-3
TO-252-4L
TO-263
TO-251S
SEM40P30D3G P-ch MOS PDFN3.3*3.3-8L -30 ±20 -40 -1 -1.5 -2.4 8 10 12 15 0 0
SEM60N30D3G N-ch MOS PDFN3.3*3.3-8L 30 ±20 60 1 1.4 2.5 4.8 6 7.1 12 0 0
SEMP3004 P-ch MOS DFN2020-6L -30 -20 -4.1 -1 0 -3 0 0 60 87 0 0
SEMP2011 P-ch MOS DFN2020-6L -20 -12 -11 -0.55 0 -1.2 0 0 17 23.5 27 40
SEM3005 N-ch MOS DFN2020-6 30 10 5 0.6 0 1 30 42 32 44 0 0
SEM4407Q P-ch MOS SOP-8 -30 -20 -12 -1 0 -2.2 9.2 13 10.7 17 0 0
SEM9435Q P-ch MOS SOP-8 -30 -20 -5.1 -1 0 -2 40 60 60 105 0 0
SEM7328DQ Dual-P SOP-8 -30 -20 -8 -1 0 -2.5 17.5 21 23 25 0 0
SEM4953DQ Dual-P SOP-8 -30 -20 -5 -1 0 -2 47 60 62 90 0 0
SEM4800DQ Dual-N SOP-8 30 12 6.9 0.7 0 1.4 20 27 22 32 0 0
SEM4824DQ Dual-N SOP-8 30 20 15 1 0 3 10.5 14 14.5 18 0 0
SEM4406Q N-ch MOS SOP-8 30 20 10 1 0 3 8 12 10 16 0 0
SEM9926DQ Dual-N SOP-8 20 12 4.8 0.6 0 1.2 0 0 21 30 27 40
SEM20DN06D2A Dual-N DFN2*2-6 20 ±12 6 0.5 0 1.2 0 0 14 16 20 24
SEM20DN08D2A Dual-N DFN2*2-6 20 ±12 8 0.5 0 1.2 0 0 12 14 19 22
SEM20DN10D2A Dual-N DFN2*2-6 20 ±12 10 0.5 0 1.2 0 0 9 12 12 15
SEM16DN06D2B Dual-N DFN2*2-6 16 ±12 6 0.5 0 1.2 0 0 12 14 20 24
SEM18DN08D2B Dual-N DFN2*2-6 18 ±12 8 0.5 0 1.2 0 0 9 11 12 15
SEM18DN10D2A Dual-N DFN2*2-6 18 ±12 10 0.5 0 1.2 0 0 7 9 11 15
SEM20DN12D2A Dual-N DFN2*3-6 20 ±12 12 0.5 0 1.2 0 0 12 14 19 22
SEM20DN16D2A Dual-N DFN2*3-6 20 ±12 16 0.5 0 1.2 0 0 9 12 12 15
SEM18DN12D2B Dual-N DFN2*3-6 18 ±12 12 0.5 0 1.2 0 0 9 11 12 15
SEM18DN16D2A Dual-N DFN2*3-6 18 ±12 16 0.5 0 1.2 0 0 7 9 11 15
SEM20DN20D2B Dual-N DFN2*3-6 20 ±12 20 0.5 0 1.2 0 0 7 9 11 15
SEM3350D3D Dual-N DFN3*3 20 ±12 30 0.5 0 1.2 0 0 4 5 4.5 5.5
SEM3325D3D Dual-N DFN3*3 17 ±12 30 0.5 0 1.2 0 0 2.2 3 3.5 4.5
SEM18DN22D2A Dual-N DFN2*5-6 18 ±12 22 0.5 0 1.2 0 0 5 6 7 10
SEM18DN20D2A Dual-N DFN2*5-6 18 ±12 20 0.5 0 1.2 0 0 6.5 7.5 9 12
SEM8810DQ Dual-N TSSOP8-6 20 ±12 12 0.5 0 1.2 0 0 14 16 19 22
SEM8814DQA Dual-N TSSOP8-6 20 ±12 16 0.5 0 1.2 0 0 10 12 13 18
First 1 2 3 4 5 6 ... Next Last There Are176
